Conn-Link Technology Inc
Description
  • USB2.0 A Type
  • 4+4Pins Receptacle
  • Stacked Type
  • DIP
  • Gold Flash Plating
  • Shield with Spring
  • Black Color

Material

  • Housing: High Temperature Thermoplastics UL 94V-0.
  • Color: Black.
  • Contact: Copper Alloy.
  • Plating: Gold Plating over Nickel on Contact Area;
    Tin Plating over Nickel on Solder Tail.
  • Shield: SPCC-SD.

Mechanical

  • Insertion Force: 35N Max.
  • Withdrawal Force: 10N Min Initial; 8-20N after 1000Cycles.
  • Durability: 100 cycles.

Electrical Specification

  • Current Rating: 1.0Ampere at 30VDC.
  • Contact Resistance: 30mΩ Max Initial; 40mΩ after 1000Cycles.
  • Insulation Resistance: 1000MΩ Min.
  • Dielectric Withstanding Voltage: 500 VAC 1 Sec. Level.

Environmental

  • Operating Temperature: -30°C to +80°C
  • RoHS Compliance.
