Description
- 2.0mm SMD Series
- Vertical
- Wire to Board
- 02~16Pins
- With Cap
- PA9T
- Natural Color
- MOQ=800PCS/Reel
Material
- Housing: Nylon 9T, UL 94V-0 Rated.
- Color: White.
- Contact: Phosphor Bornze.
- Plating: Tin Plating over Nickel.
Tin Plating on Solder Tail.
- Nail Pad: Phosphor Bornze.
- Plating: Tin Plating over Nickel.
- Cap: Nylon PA46, UL 94V-0 Rated.
Electrical Specification
- Operation Voltage: 100V AC/DC.
- Current Rating: 2 Ampere AC/DC per Contact.
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Dielectric Withstanding Voltage: 800V AC per Minute.
Environmental
- Operating Temperature: -25°C to +85°C.
- Package: 800pcs/Reel.
- RoHS Compliance.
![]()
![]()
