Conn-Link Technology Inc
  • 1.00mm SMT Series Wire to Board
  • 02~22Pins
  • Vertical
  • PA9T
  • Natural Color
  • 1K/Reel


  • Housing: Nylon 9T, UL 94V-0 Rated.
  • Color: White.
  • Contact: Phosphor Bronze.
  • Plating: Tin Plating over Nickel.
    Tin Plating on Solder Tail.

Electrical Specification

  • Operation Voltage: 125V AC/DC.
  • Current Rating: 1 Ampere AC/DC per Contact.
  • Contact Resistance: 20mΩ Max.
  • Insulation Resistance: 100MΩ Min.
  • Dielectric Withstanding Voltage: 500V AC per Minute.


  • Operating Temperature: -25°C to +85°C.
  • Package: 1,000pcs/Reel, with Cap.
  • RoHS Compliance.
